What is a 3D OEE system?
A 3D OEE system is a unified manufacturing platform that combines real-time machine connectivity (PLC/IoT) with AI-powered Computer Vision and native maintenance execution (CMMS) to ensure that every production loss is identified, visually verified, and resolved through an automated workflow.
Most vendors sell 1D (Manual logs) or 2D (PLC dashboards) systems.
Fabrico is the first System of Action built on the 3D framework, ensuring that Mike (the Tactical Manager) isn't just "keeping score," but actively engineering uptime.
Dimension 1: The Pulse (Real-Time PLC Connectivity)
The first dimension is the baseline: capturing every cycle, micro-stop, and scrap event with millisecond precision.
Without direct PLC or IoT connectivity, your OEE software relies on "Pencil Whipping"—manual logs that are often 30% inaccurate.
Fabrico pulls this "Pulse" data directly from your lines, providing the objective foundation for your Availability and Performance scores.
This captures the Hidden Factory inefficiencies that human operators often overlook during high-speed shifts.
Dimension 2: The Truth (Computer Vision & RCA)
The second dimension is visual proof.
A PLC can tell you that a machine stopped, but it cannot tell you why a bottle tipped or a feeder jammed.
Fabrico’s Inefficiencies Zoom-In (Computer Vision) module acts as the "Eyes" of the factory.
When a performance drop is detected, the system flags a 10-second video clip of the event.
This visual truth ends the "Blame Game" between production and maintenance, allowing for a permanent Root Cause Analysis (RCA) fix rather than a temporary adjustment.
Dimension 3: The Cure (Integrated Maintenance Execution)
The third—and most critical—dimension is the bridge to action.
In 2D systems, the dashboard exists in a silo, forcing Mike to manually radio Tom (the Technician) to assign a repair.
Fabrico’s integrated OEE and CMMS automates this "Fault-to-Fix" cycle.
The moment a performance threshold is breached, the system triggers a prioritized Work Order on Tom’s mobile device.
This ensures that your maintenance effort is always applied to the Value Fulcrum—the high-impact tasks that directly protect your effective runtime.
Comparison Matrix: 1D vs. 2D vs. 3D OEE Systems
| Capability |
1D (Manual / Excel) |
2D (PLC Dashboards) |
3D (Fabrico System of Action) |
| Data Integrity |
Low (Subjective) |
High (Timing Only) |
Absolute (Data + Vision) |
| Root Cause Depth |
Zero |
Data-Only / Guessing |
Advanced Visual Zoom-In |
| Maintenance Link |
None |
Manual / Siled |
Native Integrated CMMS |
| Mobile Capability |
N/A |
Browser-Based |
Field-Ready Native App |
| Decision Latency |
Very High (Days) |
Moderate (Hours) |
Zero (Automated Triggers) |
| ROI Strategy |
Compliance |
Reporting |
Revenue Reclamation |
The Financial Blueprint: ROI through 3D Action
For Paula (the Strategic Leader), the 3D framework is a financial masterstroke that reduces the Maintenance Cost per Unit.
By identifying "Bad Actor" assets through the 80/20 Rule and providing visual proof of failure, she can move her team to Condition-Directed Tasks.
This reclaimed capacity—typically 10-15% of your OEE score—is essentially "found revenue" that requires zero additional Capex.
As the factory builds 12 months of clean 3D data, it creates the perfect foundation for the Fabrico Agent (AI Roadmap) to automate future optimizations.
Stop managing in 2D. Start engineering your profit with a 3D System of Action.
